Product Description
Main Parameters:
| Product name | Model | Capacity | Power | Machine dimensions |
| Single-channel peeling and beating machine | CQ-DYJ1-1 | 500-1000kg/h | 3kw | 850*750*1100mm |
| CQ-DYJ1-2.5 | 1500-2500kg/h | 4-7.5kw | 1550*680*1500mm |
| CQ-DYJ1-5 | 3000-5000kg/h | 11-15kw | 1950*800*1800mm |
| Double-channel peeling and beating machine | CQ-DYJ2-1 | 500-1000kg/h | 3kw+3kw | 950*850*1500mm |
| CQ-DYJ2-2.5 | 1500-2500kg/h | 5.5kw+7.5kw | 1600*1450*1900mm |
| CQ-DYJ2-5 | 3000-5000kg/h | 11kw+15kw | 1950*1750*2200mm |
Machine Features:
1. This machine can realize automatic separation of pulp and slag core.
2. This machine can be combined on the production line or produced on a stand-alone basis.
3. The parts in contact with the materials are made of high-quality stainless steel, which meets the requirements of food hygiene.
4. The main structure of this machine is the transmission system, bearing seat, cylinder back cover, baffle plate, cylinder body, shaft, screen, scraper (or beating rod), cylinder front cover, frame, etc.
5.Optional screen aperture: Φ0.6, 0.8, 1.0, 1.2, 1.6, 2, 3, 4, 6mm and other specifications.
Working Principle:
1. The motor is driven by a V-belt to make the scraper mounted on the shaft rotate at high speed. When the crushed fruit or raw fruit enters the machine through the feed port, the baffle plate will evenly discharge the material to the scraper and the screen. In between, due to the rotation of the scraper and the existence of the lead angle, the material moves along the cylinder to the outlet end. The moving track is spiral, and the material is subjected to centrifugal force during the movement between the scraper and the screen. The juice and meat (have become pulpy) pass through the screen holes and enter the next process (the double-pass beater repeats the above process for linkage), and the skin and seed cores are discharged from the slag hopper. To achieve the purpose of automatic separation.
2. According to the different raw materials, as long as the screens of different specifications are changed and the lead angle of the scraper is adjusted, different beating speeds can be changed to obtain satisfactory results.
avocado pulper remove peel stone peach skin remover watermelon scoop peeler
Product Details
avocado pulper remove peel stone peach skin remover watermelon scoop peeler
What is the ginger application:
Ginger is a flowering plant that originated in Southeast Asia. It’s healthy and delicious spices.
Ginger can be used fresh, dried, powdered, or as an oil or juice. It’s a very common ingredient in recipes. It’s sometimes added
to processed foods and cosmetics.
What is advantage of ginger juice:
New product for market. Popular and hot by trend.
